DL01

General Information

  • Integrated pressure sensor, connection via quick-release coupling
  • Storage capacity: up to approx. 4,000,000 measured values
  • Serial interface for PC
  • Power supply via lithium battery
  • Battery life: up to 10 years
  • Protection class: IP67

Options

  • Additional 3 measuring channels or inputs:
    • 1 × mA input for external sensors
    • 2 × high-resolution digital counter inputs
  • Measuring cable
  • USB adapter
  • Connection adapter for underground hydrants
  • Adapter with ¼″ and ½″ male thread
  • Adapter with ¾″ female thread

Specifications

  • Waterproof, robust stainless steel housing, IP67
  • Integrated pressure sensor:
 Measuring ranges:1.0, 1.6, 2.5, 6.0 bar
10, 16, 25, 40 bar		 (-p01, -p016, -p025, -p06)
(-p10, -p16, -p25, -p40)
 Linearity error:≤ 0.50 % of full-scale range
≤ 0.25 % of full-scale range
≤ 0.10 % of full-scale range		 (-T05)
(-T025)
(-T01)
(optional)
(optional)
  • Maximum of 1 analogue input for external sensors
    • Resolution: 0.007 % (accuracy: 0.02 %)
  • Adjustable measuring interval: 1 second to 30 days
  • Switched sensor supply by the logger: (3 V ± 3 %, max. load 10 mA)
  • Storage capacity: up to approx. 4,000,000 measured values
  • Battery capacity: 2.6 Ah
  • Dimensions: 140 mm × 36 mm (L × D)
  • Weight: 350 g

Operating time

Operating time without battery replacement under standard conditions:



channels



Measuring interval



5 seconds

1 minute

1 hour

1 × pressure



2 months

6 months

10 years

2 × counter



2 months

6 months

10 years

1 × pressure +
2 × counter



2 months

4 months

10 years
